Lab 12: Building a GUI with JavaFX and Scene Builder

Learning Objectives

• Use Scene Builder to visually create an FXML layout
• Wire FXML to a Controller using fx:id and @FXML annotations
• Implement the MVC pattern with pre-built SceneItAll Model classes
• Use property binding to synchronize the View with the Model
• Write a ViewModel unit test without starting the JavaFX runtime
• Write an E2E test using TestFX with accessibility-based locators
• Practice pair programming: driving, navigating, and switching roles

Overview

In Lab 10 you evaluated someone else's finished UI. In Lab 11 you designed a UI on paper and watched someone try to use it. Today you close the loop: pair up with a partner and build a working GUI together.

You'll use the same SceneItAll domain from Lab 11 — and you can reuse either partner's paper prototype design or start fresh. The starter code provides the Model classes (Light, Fan, Shade, Area, Scene), a ViewModel skeleton, and test scaffolding. You fill in the View, Controller, and tests — together.

Pair Programming

This lab uses pair programming — two people, one computer. One person is the driver (hands on keyboard, writes code). The other is the navigator (reads along, thinks ahead, catches mistakes, suggests ideas). Swap roles every ~10 minutes. Both of you are always engaged — the navigator is not on their phone.

Why? Because GA1 is a team project, and the hardest part of team software development isn't the code — it's communicating about the code. Pair programming forces you to articulate your thinking out loud, which is exactly the skill you need for code walks and PR reviews.

Connection to GA1

Everything you practice today — Scene Builder, FXML wiring, the @FXML lifecycle, property binding, ViewModel testing, E2E testing, and collaborating on code — is exactly what you'll do for your GA1 Core Features implementation. This lab is your dress rehearsal.

---

Part 1: Setup & Pair Formation (15 min)

For TAs Walk through Scene Builder at the front of the room before students start. Show:

opening an FXML file (File → Open or Open Project), dragging a VBox, dropping a Button inside it, setting fx:id in the Code panel, setting accessibleText in the Properties panel, and saving. This should take ~5 minutes, then have students pair up and set up. Make sure students have Scene Builder installed before starting — the install instructions are in the Setup section below. Remind students they can also use Claude Code or Copilot to tweak FXML files directly.

Pairing rules: Pairs should NOT be GA1 teammates — fresh collaborators help build broader team skills. If odd numbers, make one group of three with a rotating navigator. :::

Form pairs

Find a partner — not someone from your GA1 team. Sit at one computer together. Decide who drives first (you'll swap in Part 2).

Get the starter project

One person clones the Lab 12 repository from Pawtograder. This is the shared codebase you'll both work on.

The project contains:

File	What it is	What you do with it
src/main/java/sceneitall/model/	Model classes: Light, Fan, Shade, Area, Scene	Don't modify. These are your domain logic.
Reference implementation (read, don't modify):
src/main/java/sceneitall/viewmodel/AreaDashboardViewModel.java	Complete ViewModel from L29/L30 — working example with properties, binding, activateScene()	Read as reference. This is the worked example from lecture.
src/main/java/sceneitall/controller/AreaDashboardController.java	Complete Controller from L29 — FXML wiring, initialize, handlers	Read as reference.
src/main/resources/area-dashboard.fxml	Complete FXML from L29 — the Area Dashboard layout	Read as reference. You can run it to see a working app.
src/test/java/sceneitall/viewmodel/AreaDashboardViewModelTest.java	Complete ViewModel tests — several examples showing the testing patterns	Read as reference.
src/test/java/sceneitall/AreaDashboardE2ETest.java	Complete E2E test — TestFX with findByAccessibleText()	Read as reference.
Your task (pick one, build it):
src/main/java/sceneitall/viewmodel/SceneBuilderViewModel.java	Skeleton — properties declared, methods are TODOs	Fill in command methods
src/main/java/sceneitall/viewmodel/DeviceSetupViewModel.java	Skeleton — properties declared, methods are TODOs	Fill in command methods
src/main/java/sceneitall/viewmodel/ScheduleViewModel.java	Skeleton — properties declared, methods are TODOs	Fill in command methods
src/main/java/sceneitall/controller/*Controller.java	Empty Controller for each task	Pick one, fill in @FXML fields, initialize(), bindings
src/main/resources/*-task.fxml	Empty FXML for each task	Pick one, build your layout in Scene Builder
src/test/java/sceneitall/viewmodel/*ViewModelTest.java	Test scaffold for each task — one TODO	Write one test
src/test/java/sceneitall/*E2ETest.java	TestFX scaffold for each task — start() pre-wired	Write one test
Shared:
src/main/resources/styles.css	Dark theme from L29 (optional)	Use it or ignore it
src/main/java/sceneitall/SceneItAllApp.java	Application class — loads your chosen FXML (change the path)	Update FXML path to point to your task

Use the reference implementation

Before you start building, run the Area Dashboard to see what a complete SceneItAll GUI looks like. It's the same example from L29 and L30 — complete FXML, Controller, ViewModel, and tests. Study how the pieces connect:

• How does fx:id="brightnessSlider" in the FXML map to @FXML private Slider brightnessSlider in the Controller?
• How does initialize() set up the binding?
• How does the ViewModel test call activateScene() without any JavaFX widgets?
• How does the E2E test find elements by accessibleText?

You're building a different task, but the patterns are identical. Use the reference to answer "how do I...?" questions as you work.

Install Scene Builder

Scene Builder is a standalone visual editor for FXML files. You'll use it to build your GUI layout by dragging and dropping components.

1. Download Scene Builder from Gluon (free, choose your OS)
2. Install it — on macOS, open .dmg file and drag Scene Builder to Applications; on Windows, run the installer
3. Open Scene Builder, then go to File → Open or Open Project and select your task's .fxml file (e.g., src/main/resources/scene-builder-task.fxml)

After editing in Scene Builder, save (Cmd+S / Ctrl+S) — the FXML file updates in place. Switch back to VS Code to see the changes and write your Controller code.

AI-Assisted FXML Editing

You can also use Claude Code or GitHub Copilot to tweak your FXML files directly — for example, "add a ComboBox below the ListView with fx:id deviceComboBox and accessibleText Select device" or "change the VBox spacing to 12 and add padding." This is often faster than switching between Scene Builder and VS Code for small adjustments. Northeastern students get $200/month of Claude Code usage when signing in with their northeastern.edu account.

Running the app

To launch the GUI:

./gradlew run

This starts SceneItAllApp, which loads whichever FXML file is set in SceneItAllApp.java. By default it loads the Area Dashboard reference implementation. When you start your task, change the FXML_PATH constant to point to your task's FXML (e.g., "/scene-builder-task.fxml").

Running the tests

To run all tests (ViewModel tests + E2E tests):

./gradlew test

To run just the ViewModel tests (fast, no GUI window):

./gradlew test --tests 'sceneitall.viewmodel.*'

To run just the E2E tests (launches a GUI window briefly):

./gradlew test --tests 'sceneitall.*E2ETest'

To run a specific test class:

./gradlew test --tests 'sceneitall.viewmodel.AreaDashboardViewModelTest'

Verify your setup

1. Open the project in VS Code
2. Open Scene Builder and use File → Open or Open Project to open src/main/resources/area-dashboard.fxml — you should see the Area Dashboard layout
3. Run ./gradlew run — you should see a window titled "SceneItAll" with the Area Dashboard
4. Run ./gradlew test — the reference tests should pass; scaffold tests should pass

NullAway and @FXML fields @FXML fields are injected by FXMLLoader at runtime, after the

constructor runs — so they look uninitialized to NullAway. The skeleton Controllers handle this with @NullUnmarked (from JSpecify) at the top of the class, which tells NullAway that null analysis doesn't apply here because the framework handles initialization. Copy that pattern in your Controller.

For ViewModel backing-model fields (area, areas), the skeletons use @Nullable from JSpecify, which is accurate — those fields genuinely are null until setArea()/setModel() is called. When you implement the TODO methods, use Objects.requireNonNull(area, "Call setArea() first") to get a non-null local reference NullAway is happy with.

Known build warnings You'll see some warnings when you build — this is normal:

• UnusedVariable / UnusedMethod false positives on @FXML fields and private handler methods (called reflectively by FXMLLoader, so Error Prone can't see the usages)
• "Unknown module: javafx.graphics" and "Unsupported JavaFX configuration" during tests (harmless TestFX/module-system noise)

None of these indicate a problem with your code.

---

Part 2: Build Your Area Dashboard — Pair Programming (30 min)

Pick one of the three SceneItAll design tasks below. You can reuse either partner's Lab 11 paper prototype or start fresh. Decide together.

Not Area Dashboard

The Area Dashboard was the running example in L29 and L30 — you've already seen the complete FXML, Controller, ViewModel, and tests for it. Pick a different task so you practice applying the patterns yourself, not reproducing lecture code. The lecture example is there as a reference, not a template to copy.

Design Task	What to build	How it differs from the lecture example
Scene Builder	Interface for creating/editing a Scene — select devices, set target states, name the scene, assign to a room	Multiple device controls in one view, creating a new domain object (sceneitall.model.Scene) rather than displaying existing ones. Uses setArea(Area) (single area). Note: Watch out for the name collision with javafx.scene.Scene — use the fully qualified name when both are in scope.
Device Setup	Scan for devices, name one, pick a type, assign to a room, save	Validation (device name required, room must be selected), new device added to Model, uses TextField and DeviceType enum not shown in reference. Uses setModel(List<Area>) (multiple rooms).
Schedule & Automation	Interface for creating automated rules — "at sunset, activate Evening in Living Room"	Multiple selection inputs with validation. Uses setModel(List<Area>). Note: The model doesn't include scheduling/automation concepts — you'll represent rules as formatted Strings in the ViewModel's ObservableList<String>

Swap roles at least twice during this part (roughly every 8-10 minutes). The TA may call out role swaps.

For TAs Call out "swap!" at roughly 10-minute intervals during Part 2. Watch for pairs where

the navigator has disengaged — redirect them. The navigator should be actively reading, suggesting, and catching issues ("that fx:id doesn't match the field name", "should that be in initialize() instead?").

Phase A: Build the FXML (Driver 1, ~12 min)

Driver builds the layout in Scene Builder. Navigator has the Lab 11 paper prototype (or a fresh design sketch) open as reference and guides the layout decisions.

Your layout must include at minimum:

• A title label (e.g., room name or "Add Device")
• One interactive control — Slider, ComboBox, Spinner, or ToggleButton
• A ListView showing device statuses or scene items
• One action Button (e.g., "Activate Scene", "Add Device", "Save Rule")

For each component:

• Set fx:id in the Code panel (e.g., brightnessSlider)
• Set accessibleText in the Properties panel for any widget that doesn't have visible text. This must match exactly (case-sensitive) what your E2E test uses in findByAccessibleText().
• Set onAction for your Button → #handleYourAction

Navigator: Check that every fx:id follows a consistent naming convention. Check that every interactive widget has accessibleText. Reference the paper prototype — are you building what you designed?

🔄 Swap roles!

Phase B: Wire ViewModel & Controller (Driver 2, ~12 min)

Driver writes the Java code. Navigator has the FXML open (or Scene Builder) and cross-references the fx:ids against the @FXML field names.

Start with the ViewModel (so the Controller can call its methods without crashing):

Fill in the ViewModel for your chosen task. Each skeleton has properties declared and TODO methods:

• SceneBuilderViewModel: addDeviceToScene(), removeDeviceFromScene(), saveScene()
• DeviceSetupViewModel: scanForDevices(), selectDevice(), assignToRoom(), saveDevice()
• ScheduleViewModel: setTrigger(), setAction(), saveRule()

Implement enough TODO methods for one complete user flow (e.g., add a device to a scene and save it). In practice this means at least 2 methods, often all of them — they tend to depend on each other.

Then wire the Controller:

1. Add @FXML fields matching your fx:ids
2. In initialize(), create sample data — build Area objects with devices and/or scenes, similar to createSampleArea() in the reference Controller. Your ViewModel needs data to display.
3. Create the ViewModel and connect it to the model (setArea() or setModel())
4. Bind widgets to ViewModel properties. Use bind() for display-only Labels; use bindBidirectional() for TextFields where user input should flow back to the ViewModel. The reference only shows bind() (one-way) because it only has Labels and a Slider listener — your task may need bidirectional binding for TextFields.
5. Set up listeners for ComboBox selection, slider changes, etc. (see the reference Controller's ComboBox listener pattern: comboBox.getSelectionModel().selectedItemProperty().addListener(...))
6. Implement your button handler — delegate to the ViewModel
7. Your Controller skeleton already has @NullUnmarked at the class level — no action needed. In your ViewModel implementations, use Objects.requireNonNull(area, "Call setArea() first") (or areas) to satisfy NullAway where the backing model field is @Nullable.

Implement ViewModel methods before wiring Controller listeners If your Controller sets up

listeners that call ViewModel TODO methods (like selectDevice() or assignToRoom()), those listeners will fire during initialize() and throw UnsupportedOperationException. Implement the ViewModel methods first.

Navigator: Watch for the #1 lifecycle bug — code that touches @FXML fields in the constructor instead of initialize(). Watch for fx:id / field name mismatches. Your task may require widgets not shown in the reference (e.g., TextField, ComboBox<Enum>) — check the JavaFX docs or ask your partner. Think ahead: "after we wire this, how will we test it?"

🔄 Swap roles!

Phase C: Run & Polish (Both, ~6 min)

Launch SceneItAllApp together. Both of you look at the running GUI:

• Click your button — does the device list update?
• Drag the slider — does the value change?
• Tab through the GUI — can you reach every widget?

Fix anything broken. The navigator from Phase B should now drive the fixes.

---

Part 3: Test (10 min)

Why test last? You might wonder: shouldn't we write tests first? In GUI development, there's

a real cost to writing tests too early. If you'd written E2E tests before seeing the running app, those tests would assert on the old layout and break when you polish it.

This is a key difference from domain logic testing (where test-first works great). GUI tests are expensive to write and fragile when the interface is still evolving. The professional pattern is: explore manually first (including having someone else try your UI), stabilize the design, then lock it down with automated tests. ViewModel tests are more stable since they don't depend on layout — but E2E tests should wait until you're confident in the interaction design.

In GA1, you'll blend both: write ViewModel tests early (they're cheap and stable), but save E2E tests for after your feature's UI has settled.

Write one ViewModel test (one partner drives)

Open the ViewModel test file for your chosen task. The scaffold has one example test and one TODO. Write a test that:

1. Creates a ViewModel and sets a Model with test data
2. Calls one of the command methods you implemented
3. Asserts on a property value

Examples for each task:

// Scene Builder task — addDeviceToScene() reads from properties, not parameters
// testArea is built in @BeforeEach (see scaffold)
@Test
void addDeviceToScene_updatesDeviceList() {
    SceneBuilderViewModel vm = new SceneBuilderViewModel();
    vm.setArea(testArea);                              // setArea(), not setModel()
    vm.selectedDeviceProperty().set("Ceiling Light");  // set properties first
    vm.targetValueProperty().set(30);

    vm.addDeviceToScene();                             // no parameters — reads from properties

    assertThat(vm.getSceneDevices()).anyMatch(s -> s.contains("Ceiling Light"));
}

// Device Setup task — setModel() takes List<Area>, not setArea()
@Test
void assignToRoom_updatesRoomProperty() {
    DeviceSetupViewModel vm = new DeviceSetupViewModel();
    vm.setModel(List.of(new Area("Living Room"), new Area("Bedroom")));
    vm.selectDevice("New Light");                      // accepts any name, not just scanned ones

    vm.assignToRoom("Bedroom");

    assertThat(vm.assignedRoomProperty().get()).isEqualTo("Bedroom");
}

// Schedule task — setAction() takes 2 parameters (scene, area), not 3
@Test
void saveRule_addsToRuleList() {
    ScheduleViewModel vm = new ScheduleViewModel();
    vm.setModel(testAreas);
    vm.setTrigger("Sunset");
    vm.setAction("Evening", "Living Room");            // 2 params, not 3

    vm.saveRule();

    assertThat(vm.getRules()).isNotEmpty();
}

Run it. It should pass in milliseconds — no JavaFX runtime needed.

🔄 Swap! Write one E2E test (other partner drives)

Open the E2E test file for your chosen task. The scaffold has start() pre-wired and a findByAccessibleText() helper. Study AreaDashboardE2ETest carefully before writing your own — it uses interact() to run actions on the JavaFX thread, which is more reliable than clickOn() for ComboBox selections and button clicks. Write a test that:

1. Finds widgets by accessibleText and casts them to their types (e.g., ComboBox, Button)
2. Uses interact(() -> { ... }) to manipulate widgets programmatically
3. Calls WaitForAsyncUtils.waitForFxEvents() after interactions
4. Asserts on a visible result using AssertJ's assertThat

Examples for each task:

// Scene Builder task — use interact() for reliable widget manipulation
@Test
void userCanAddDeviceToScene() {
    @SuppressWarnings("unchecked")
    ComboBox<String> deviceCombo =
        (ComboBox<String>) findByAccessibleText("Select device");
    Slider targetSlider = (Slider) findByAccessibleText("Target value");
    Button addBtn = (Button) findByAccessibleText("Add device to scene");

    interact(() -> {
        deviceCombo.getSelectionModel().select("Ceiling Light");
        targetSlider.setValue(30);
        addBtn.fire();
    });
    WaitForAsyncUtils.waitForFxEvents();

    @SuppressWarnings("unchecked")
    ListView<String> devices =
        (ListView<String>) findByAccessibleText("Devices in scene");
    assertThat(devices.getItems().stream()
        .anyMatch(s -> s.contains("Ceiling Light"))).isTrue();
}

// Device Setup task
@Test
void userCanAddNewDevice() {
    TextField nameField = (TextField) findByAccessibleText("Device name");
    @SuppressWarnings("unchecked")
    ComboBox<String> roomCombo =
        (ComboBox<String>) findByAccessibleText("Choose a room");
    Button saveBtn = (Button) findByAccessibleText("Save device");

    interact(() -> {
        nameField.setText("Desk Lamp");
        roomCombo.getSelectionModel().select("Bedroom");
        saveBtn.fire();
    });
    WaitForAsyncUtils.waitForFxEvents();

    Label status = (Label) findByAccessibleText("Status message");
    assertThat(status.getText()).contains("saved");
}

// Schedule task — note: must select trigger, scene, AND area before saving
@Test
void userCanCreateAutomationRule() {
    @SuppressWarnings("unchecked")
    ComboBox<String> triggerCombo =
        (ComboBox<String>) findByAccessibleText("Select trigger");
    @SuppressWarnings("unchecked")
    ComboBox<String> sceneCombo =
        (ComboBox<String>) findByAccessibleText("Select scene");
    @SuppressWarnings("unchecked")
    ComboBox<String> areaCombo =
        (ComboBox<String>) findByAccessibleText("Select area");
    Button saveBtn = (Button) findByAccessibleText("Save rule");

    interact(() -> {
        triggerCombo.getSelectionModel().select("Sunset");
        sceneCombo.getSelectionModel().select("Evening");
        areaCombo.getSelectionModel().select("Living Room");
        saveBtn.fire();
    });
    WaitForAsyncUtils.waitForFxEvents();

    @SuppressWarnings("unchecked")
    ListView<String> rules =
        (ListView<String>) findByAccessibleText("Automation rules");
    assertThat(rules.getItems()).isNotEmpty();
}

Run it. This one takes a couple seconds — it launches the real GUI.

---

Part 4: Pair Programming Debrief (10 min)

For TAs Bring the class back together for a group debrief. This is the soft-skills payoff of

the lab. Ask the questions below and let 3-4 pairs share. Keep it conversational — 8 minutes of discussion, 2 minutes for reflection writing.

Class discussion — a few pairs share:

1. How did you decide who drove first? Did it matter?
2. What did the navigator catch that the driver missed? (fx:id typos? lifecycle bugs? accessibility gaps?)
3. When was it hardest to be the navigator? (When the driver was doing something you disagreed with? When you didn't understand the code? When you wanted to grab the keyboard?)
4. Did you communicate differently when pair programming vs. working alone? Did you explain your thinking more? Less?
5. How does this compare to the PR review workflow you'll use in GA1? (Pair programming is real-time review; PR review is asynchronous. Which catches more? Which is more efficient?)

---

Part 5: Reflection (5 min)

Both partners submit a REFLECTION.md through their own Pawtograder lab repository. (Only one partner needs to submit the code — the one whose repo you worked in.)

Section 1: The Build

• Which design task did you choose?
• Did you reuse a Lab 11 paper prototype? What changed between paper and code?
• Who was your partner?

Section 2: Pair Programming

• What was the most valuable thing your navigator caught while you were driving?
• What was hardest about being the navigator?
• Did pair programming change how you think about the code compared to working alone? How?

Section 3: Testing

• Paste or screenshot your passing ViewModel test
• Paste or screenshot your passing E2E test
• Which test was easier to write? Which gave you more confidence that your code works?

Section 4: Looking Ahead

• What will you do differently in GA1 based on today's experience?

---

Submission

• Code: One partner submits the shared code through their Pawtograder lab repository (FXML, Controller, ViewModel, tests)
• Reflection: Both partners submit their own REFLECTION.md through their own Pawtograder lab repository

Grading

Option 1: Running GUI + both tests passing + both partners submit reflections → full

credit.

Option 2: Submit whatever you complete along with the reflection documenting your progress, what you got stuck on, and what you learned → good-faith credit available. Attendance and genuine engagement matter more than perfection.
